Applicable fibers Silica optical fiber
Bare fiber diameter 125um
Coating diameters 250um,900um
Cleaving angle 0.5 degrees with single fiber
Cleaving length 250um: 9~16mm; 900um: 10~16mm
Blade positions 3 height and 12 rotating positions
Blade life 36,000 fibers (1,000 fibers x 3 height x 12 positions)
Dimensions(mm) 57.8W*60.5D*51.5H
Weight 315g
